Prism LED Panel Light
Features
Prism LED panel adopts high lumen SMD LED with up to 80% energy saving compared to standard CFL. Long a lifetime of 50,000 hours. The top branded driver comes with Triac dim, 0-1 OV dim, and DALI dim, it has a perfect dimming range and shares great compatibility with worldwide famous brand dimmers.120° wide beam angle. The ultra-slim profile fits seamlessly into any workplace. It is available in various installation ways: embedded into the ceiling, suspended with hanging wires, surface mounted in a concrete ceiling by using a surface mounting frame.

| Item Code | Power | Lamp | Lumen | Dimensions |
|---|---|---|---|---|
| L +PNL7035-30 | 30W | LED | 3600lm | A595 x B595 x C7.5mm |
| L+PNL7035-36 | 36W | LED | 4320lm | A595 x B595 x C7.5mm |
| L+PNL7035-40 | 40W | LED | 4800lm | A595 x B595 x C7.5mm |
| L+PNL7035-45 | 45W | LED | 5400lm | A595 x B595 x C7.5mm |
| Housing | Made of thermos painted aluminium coated. |
| Diffuser | Micro-Prismatic |
| Color Available | White |
| Lifespan | >50,000 Hours (L80 B10) |
| Reflector | Aluminium Reflector |
| Voltage | AC220~240V |
| Working Temperature | -20Co ~ +50Co |
| LED Driver | Light Plus, TriDonic, PHILIPS, OSRAM, MW |
| IP Rating | 54 |
| IK | 08 |
